SPECIFICATIONS |
|
MODEL |
6303 |
6306 |
6309 |
6315 |
6330 |
6360 |
6390 |
|
INPUT |
|
Phase |
1￠ |
3￠ |
|
Voltage |
230Vac±15% |
220/380Vac±10% |
|
Frequency |
47-63Hz |
|
OUTPUT |
|
Power rating |
Single-Phase Power |
1KVA |
2KVA |
3KVA |
5KVA |
10KVA |
20KVA |
30KVA |
|
Total Power |
3KVA |
6KVA |
9KVA |
15KVA |
30KVA |
60KVA |
90KVA |
|
Max. Current (r.m.s) |
0-150V |
8.4A |
16.8A |
25.2A |
42.0A |
84.0A |
168.0A |
252.0A |
|
0-300V |
4.2A |
8.4A |
12.6A |
21.0A |
42.0A |
84.0A |
126.0A |
|
Phase |
3￠/4W |
|
Waveform Distortion |
< 1% at 45-500Hz (Resistive Load) |
|
Crest Factor |
> 3 |
|
Line to Phase Regulation |
± (0.5% of output +0.5V) at Resistive Load |
|
Line to Line Regulation |
± (1% of output +1V) at Resistive Load |
|
Deviation of phase angle |
120° < ±1° at Load Balance, 120° < ±2.5° at 100% Load Unbalance |
|
Response Time |
< 2 msec |
|
SETTINGS |
|
Voltage |
PhaseRange |
0-150V/0-300V Selectable |
|
Resolution |
0.1V |
|
Accuracy |
±(1% of setting + 2counts) |
|
Frequency |
Range |
45-500Hz FullRange Adjust |
|
Resolution |
0.1Hz at 45-99.9Hz , 1Hz at 100-500Hz |
|
Accuracy |
±0.02% of setting |
|
MEASUREMENT |
|
Voltage |
PhaseRange |
0.0-300.0V |
|
LineRange |
0.0-520.0V |
|
Resolution |
0.1V |
|
Accuracy |
± (1% of reading + 2counts) |
|
Frequency |
Range |
0.0-500.0Hz |
|
Resolution |
0.1Hz |
|
Accuracy |
±0.1Hz |
|
Current (r.m.s) |
Range |
L |
0.000-3.500A |
0.00-35.00A |
|
H |
3.00-35.00A |
30.00-350.0A |
|
Resolution |
L |
0.001A |
0.01A |
|
H |
0.01A |
0.1A |
|
Accuracy |
L |
± (1% of reading +5counts) |
± (1% of reading +2counts) |
|
H |
± (1% of reading +1count) |
± (1% of reading +1count) |
|
Power |
Range |
L |
0.0-350.0W |
0.000-3.500KW |
|
H |
300-4000W |
3.00-40.00KW |
|
Resolution |
L |
0.1W |
0.001KW |
|
H |
1W |
0.01KW |
|
Accuracy |
L |
± (1.5% of reading +5counts) |
± (1.5% of reading +5counts) |
|
H |
± (1.5% of reading +1count) |
± (1.5% of reading +1count) |
|
Power Factor |
Range |
0.000-1.000 |
|
Resolution |
0.001 |
|
Accuracy |
Calculated and displayed to three significant digits |
|
GENERAL |
|
PLC Remote |
I/P：ON/OFF, P1, P2, P3, O/P：Processing |
|
Memory |
8 Memoies, 5steps per memory for Voltage, Frequency, Test Time, Delay time and
Current, Power, Power Factor Hi, Lo Limit setting. |
|
Timer |
0=Continuous, 1-9999. (Unit: sec, minute, hour selectable) |
|
Auto Loop Cycle |
0=Continuous, OFF=Loop Once, 2~9999. (Unit:×1, ×10, ×100) |
|
Auto Voltage Adjust |
Enable it for improve voltage regulation within ±0.1V |
|
Efficiency |
≧80%(at Full Load ) |
≧85%(at Full Load ) |
|
Protection |
Over Load , Short Circuit , Over Temperature |
|
Calibration |
Front Panel Calibration |
|
Interface (Option) |
GPIB/RS232 |
|
Environment |
0-40℃/20-80%RH |
|
Dimension (W×H×D) mm |
430×729
×650, 14U |
430×729
×650, 14U |
600×818
×900, 16U |
600×818
×900, 16U |
600×952
×900, 19U |
600×1390
×900, 28U |
900×1725
×1200, 35U |
|
Net Weight |
105Kg |
120Kg |
222Kg |
290Kg |
460Kg |
760Kg |
1200Kg |
|
product specifications are subject to change without notice. |
